The Fadal VMC 4020 is a powerful vertical machining center ideal for high-volume milling operations. It features a robust and rigid construction, a high-speed spindle, and a large working envelope that can handle a variety of part sizes.Fadal Vmc 4020

Analysis of groove processing route

For grooves with relatively small width and depth values and low precision requirements, CNC machining center.a tool with the same width as the groove can be used to directly cut and form the groove in one go.CNC machining center. After cutting the tool to the bottom of the groove, CNC machining center.a delay command can be used to briefly pause the tool to adjust the roundness of the groove bottom. During the exit process, CNC machining center.the working speed can be used.Fadal Vmc 4020

For deep groove parts with small width values but large depth values, in order to avoid the phenomenon of excessive pressure on the front of the tool and tool breakage due to poor chip removal during the cutting process, a staged cutting method should be adopted. CNC machining center.After the tool cuts into the workpiece to a certain depth,CNC machining center. it stops cutting and retracts a certain distance to achieve the purpose of chip breakage and removal. At the same time, it is important to choose tools with higher strength as much as possible.Fadal Vmc 4020

The cutting of wide grooves usually refers to grooves larger than the width of a cutting tool as wide grooves. CNC machining center.The precision requirements for the width, depth, and surface quality of wide grooves are relatively high. Rough cutting of wide grooves is often carried out using a row of cutting tools.Fadal Vmc 4020

Then use a precision grooving knife to cut along one side of the groove to the bottom, precision machine the groove to the other side, and then exit along the side.Fadal Vmc 4020
